1.Definition and Composition

The switchgear assembly line, such as low voltage electrical capacitor bank cubicle switchgear assembly line, stainless steel switchgear assembly line, and electric switchgear assembly line, usually consists of a series of workstations and machines connected together. These assembly lines are arranged in a specific order to form a continuous assembly line, enabling the automatic transfer of switchgear and completion of various processes during the entire manufacturing process. Each type has its own unique features while sharing common components. Generally, they all include traction members, load - bearing members, driving devices, tensioning devices, redirection devices, and support members.

2.Classification

According to the conveying method, different switchgear assembly lines, including low voltage electrical capacitor bank cubicle switchgear assembly line, stainless steel switchgear assembly line, and electric switchgear assembly line, can be roughly divided into seven categories: belt assembly line, plate chain line, speed chain, plug - in line, mesh belt line, suspension line and roller assembly line. The conveyor of these assembly lines can be horizontal, inclined and vertical conveying, and can also form space conveying lines. The conveying line is generally fixed, but the design and requirements may vary depending on the specific type of switchgear assembly line. For example, the stainless steel switchgear assembly line may have more stringent requirements for anti - corrosion and wear - resistance of the conveyor due to the characteristics of stainless steel materials.

3.Advantages

• Improvement of production efficiency: The automated low voltage electrical capacitor bank cubicle switchgear assembly line, stainless steel switchgear assembly line, and electric switchgear assembly line can realize continuous operation, which greatly improves the production efficiency and meets the large demand for switchgear in the market. For instance, when 40.5kV circuit breaker is produced in the electric switchgear assembly line, the daily production capacity can be up to 4 units/8 hours, and the annual production capacity can be up to 1,000 units/year (based on 8 hours/shift, 250 days/year), and the production beat is 1 unit/2 hours.

• Reduced Costs: These assembly lines help reduce production costs while ensuring consistent product quality. The modular design of the low voltage electrical capacitor bank cubicle switchgear assembly line, for example, allows for more efficient material utilization and lower maintenance costs.

• Modular design for easy upgrading: The line body of these assembly lines adopts modular design, which can be freely spliced. Each standard section is set with a 1 minute 2 air source and 220V five - port two - port power supply interface to provide tools for use during testing. The alignment slot is hidden in the lower part of the drum, facilitating easy maintenance and upgrading in the later stage, especially beneficial for the stainless steel switchgear assembly line where frequent cleaning and part replacement may be required.

4.Operation and Maintenance Points

Operating Procedures

• For all types of switchgear assembly lines, including low voltage electrical capacitor bank cubicle switchgear assembly line, stainless steel switchgear assembly line, and electric switchgear assembly line, the machine needs good grounding protection measures. Before starting the machine, you need to check whether the air tube is broken or leaking, and whether the socket and power cord are broken or not.

• Turn on the main switch of the power supply of the assembly line, open the door of the control box on the assembly line, and press the switch of fluorescent lamp, socket and conveying motor. Before starting the conveyor switch, should confirm that there is no foreign matter on the conveyor belt. After starting the conveyor switch, observe whether the conveying speed is in line with the requirements of the process. If it is too fast, twist the governor left; if too slow, twist the governor right, and adjust it before trying to start working.

• After the normal start, you need to listen carefully to the machine whether there is a strange noise, check whether the conveyor belt has stagnation, run off the phenomenon. After the work is finished, turn off the power.

Maintenance

• It is forbidden to adjust the conveying speed too fast for all these assembly lines.

• If you find any jamming or other abnormalities in the conveying, stop the operation immediately, check the reasons and remove the faults before restarting.

• Turn off the power switch at the end of the day and clean up the assembly line.

• Frequently check whether the power cord is broken, whether the switch is sensitive, whether the socket is firm, whether the fluorescent lamp can start.

• Add grease to the bearings once a month, and replace the lubricating oil once every six months to one year, which is crucial for maintaining the long - term stable operation of the low voltage electrical capacitor bank cubicle switchgear assembly line, stainless steel switchgear assembly line, and electric switchgear assembly line.
