Gas Meter Production Line

The design and realization of a gas meter production line involves a number of components, including material preparation, component assembly, testing and packaging. Gas meter production lines usually use automated assembly lines to increase productivity and reduce labor costs.

Details

1.Core production link

Our gas meter production solutions feature three specialized lines: the gas meter automatic production line, gas meter conveyor production line, and gas flowmeter production line, each optimized for specific manufacturing needs while sharing key processes.

In the gas meter automatic production line, base meter unboxing and palletizing are the initial steps. After the base meter is retrieved from the warehouse, it's conveyed to the elevator via the unpacking line and RGV, then transported to the static area by AGV. This ensures the base meter stabilizes before metering. The gas meter conveyor production line takes over at this stage, using conveyor belts and pallets to transport the base meters to the robotic gripping and loading stations. Here, robots precisely pick up the base meters and place them on the metering loading line of the gas meter automatic production line for code scanning, metering, and function testing. For the gas flowmeter production line, additional calibration procedures are integrated during the metering and testing phase to ensure accurate flow rate measurements. Finally, all products from these three lines complete the production process through laser marking and automatic packaging on the gas meter automatic production line.


2.Technical features

  • High degree of automation: The gas meter automatic production line is equipped with an automatic unpacking device, RGV conveying equipment, AGV automatic guided vehicle, and robotic hands, achieving full automation in material conveying, gripping, and loading. The gas meter conveyor production line ensures seamless material transfer between stations, further enhancing efficiency. Together, they reduce manual intervention and improve overall production efficiency.

  • High-precision detection: All three lines, including the gas meter automatic production line, gas meter conveyor production line, and gas flowmeter production line, utilize the sonic nozzle gas meter calibration device. By measuring the gas flow rate at the sonic speed in the nozzle throat, these lines accurately determine the display value error of the inspected gas meters, ensuring precise measurement results. The gas flowmeter production line has additional sensors and algorithms for more refined flow rate accuracy control.

  • Intelligent control: Through the PLC control system and MES system, real-time monitoring, data collection, and analysis are realized across the gas meter automatic production line, gas meter conveyor production line, and gas flowmeter production line. This intelligent control optimizes the production process, improves production management, and enables quick adjustments for different product requirements.

  • Flexibility and flexibility: With modular and expandable designs, all three production lines can quickly adapt to different models and specifications. The gas meter automatic production line can adjust production parameters for various gas meter types, while the gas meter conveyor production line can modify its conveying path and speed. The gas flowmeter production line is designed to easily integrate new calibration procedures for different flowmeter models.


3.Application Advantages

  • Enhance production efficiency: The gas meter automatic production line and gas meter conveyor production line work in tandem to significantly shorten the production cycle. For instance, in the gas meter production line of a leading enterprise, the single-station assembly time is within 15 seconds per piece, enabling the completion of over 4 products per minute. The gas flowmeter production line also maintains high productivity with its optimized calibration and testing processes.

  • Ensure product quality: High-precision testing equipment and strict quality control processes across the gas meter production line, gas meter conveyor production line, and gas flowmeter production line ensure that each product undergoes rigorous testing. This results in an impressive pass rate of up to 99.8%.

  • Reduce production costs: Automated production on these three lines reduces labor costs. Additionally, by optimizing the production process, energy consumption and waste emissions are minimized. The gas meter conveyor production line's efficient material transfer and the gas meter automatic production line's streamlined operations contribute to cost savings.

  • Enhance market competitiveness: The high flexibility of the gas meter production line, gas meter conveyor production line, and gas flowmeter production line allows the company to quickly respond to market demands. Whether it's producing standard gas meters on the gas meter automatic production line, handling bulk material transfer with the gas meter conveyor production line, or manufacturing specialized gas flowmeters on the gas flowmeter production line, the company can offer diversified and customized products.

gas meter automatic production line
